Cable-Driven Parallel Robots: Theory and Application

Cable-driven parallel robots are a new kind of lightweight manipulators with excellent scalability in terms of size, payload, and dynamics capacities. For the first time, a comprehensive compendium is presented of the field of cable-driven parallel robots. A thorough theory of cable robots is setup leading the reader from first principles to the latest results in research.

The main topics covered in the book are classification, terminology, and fields of application for cable-driven parallel robots. The geometric foundation of the standard cable model is introduced followed by statics, force distribution, and stiffness. Inverse and forward kinematics are addressed by elaborating efficient algorithms. Furthermore, the workspace is introduced and different algorithms are detailed. The book contains the dynamic equations as well as simulation models with applicable parameters. Advanced cable models are described taking into account pulleys, elastic cables, and sagging cables.

For practitioner, a descriptive design method is stated including methodology, parameter synthesis, construction design, component selection, and calibration. Rich examples are presented by means of simulation results from sample robots as well as experimental validation on reference demonstrators. The book contains a representative overview of reference demonstrator system. Tables with physical parameters for geometry, cable properties, and robot parameterizations support case studies and are valuable references for building custom cable robots.

For scientist, the book provides the starting point to address new scientific challenges as open problems are named and a commented review of the literature on cable robot with more than 500 references are given.

Table of Contents

Chapter 1 Introduction
Chapter 2 Classification And Architecture
Chapter 3 Geometric And Static Foundations
Chapter 4 Kinematic Codes
Chapter 5 Workspace
Chapter 6 Dynamics
Chapter 7 Kinematics With Nonstandard Cable Models
Chapter 8 Design
Chapter 9 Practice
Chapter 10 Summary
Appendix A Notation and Definitions
Appendix B Introduction to Interval Analysis
