Electronics Practicals: Real World Circuits Applications (Volume 1)

The study of electronics is one of the basic steps in gaining an understanding of all modern technology and science also; our everyday life depends a lot on the electronic. So this book of electronics practicals provides a comprehensive and clear coverage of electronic practical concepts, practical applications and troubleshooting. In this book many topics have been strengthened and some topics, innovative and features have been added related to the real world. These practical topics are coordinated with the text showing working principles and their practical design and will make any candidate to be more effective in practical application. Additionally, real world circuits design make the book more visually interesting and easier to use. The circuit provided have been simulated using reliable and accurate method and tested using real components. This Electronics Practicals book will help to strengthen TECHNICAL and ENGINEERING EDUCATION with practical skills.

Table of Contents

Chapter 1: Symbols, Units and Quantities
Chapter 2: Electronic Hand Tools
Chapter 3: Electronic Signal Generators and AC Supply
Chapter 4: Basic electronic Measuring Instruments
Chapter 5: Electronic Passive Components
Chapter 6: Diode rectifier
Chapter 7: Regulated DC power Supply – Voltage stabilization principle
Chapter 8: Voltage Clipper
Chapter 9: Volatge clamper
Chapter 10: Volatge multiplier
